Steam Generators
Revival Vapor 9
Steam that arrives soft.
9 kW generator for steam rooms up to 12 m³, with automatic drain and descale cycle.
- Output
- 9.0 kW
- Room volume
- 8–12 m³
- Supply
- 400V 3N~
- ✓Supplied and installed by Revival in Nepal
- ✓Critical spares held in Kathmandu
- ✓2-year warranty, Revival Care available
9.0 kW · 8–12 m³Request quote
The part that fails first, engineered to last
Almost every steam room failure in Nepal is scale. Vapor 9 drains and flushes the tank after every session, and the element is removable without pulling the unit — a descale is an hour, not a replacement.
Specifications
Performance
- Output power
- 9.0 kW
- Steam output
- 12 kg/h
- Room volume
- 8–12 m³
- Time to steam
- 6–8 min
Electrical & water
- Voltage
- 400V 3N~ 50 Hz
- Current
- 3 × 13 A
- Water supply
- 15 mm, 1–5 bar
- Drain
- 22 mm to tundish, gravity fall
- Auto drain
- After every session
Physical
- Dimensions (W×D×H)
- 500 × 240 × 620 mm
- Weight, dry
- 24 kg
- Location
- Within 12 m of the steam room
- Warranty
- 2 years
Installation requirements
What the room has to provide
Published so your architect, electrician and contractor can plan around it — before the walls close.
- Electrical
- 3-phase, 400V, 3 × 20 A MCB with 30 mA RCD, isolator adjacent to the unit.
- Cable
- 5 × 4 mm² to the generator; 4-core control cable to the room panel.
- Clearances
- 300 mm above and 150 mm each side for service access.
- Ventilation
- Plant space must be ventilated and stay below 40 °C.
- Room build
- Tanked and tiled room with a 1:80 fall to drain; no timber inside the wet zone.
- Drainage
- 22 mm gravity drain to a tundish — never a direct connection.
- Water
- Softened supply below 150 ppm hardness. Kathmandu mains typically requires treatment.
- Steam head must be at least 200 mm above floor and away from the seat.
- Room ceiling needs a 1:100 fall so condensate runs to the wall, not onto the user.
What Revival delivers
Every system on this site is supplied with the work that makes it function — which is the difference between buying equipment and owning a wellness environment.
- ✓Product supply
- ✓Technical sizing
- ✓Installation
- ✓Commissioning & testing
- ✓User training
- ✓Warranty & Revival Care
Complete the system
steam
Revival Hammam
Heated stone bench, marble surfaces and a tanked envelope — a full hammam built into the room.
Heated stone, 38–42 °C · 10–20 m³ · Tanked and tiled
Hotel · Commercial
Downloads
Specifying this system? The full library — CAD details, BIM families, load data and specification text — is at Revival for Professionals.
Questions
- Do we need a water softener?
- In the Kathmandu valley, almost always. Untreated supply here runs well above 150 ppm and will scale a generator within a season. We size the treatment with the generator.
